• FD31822 black bronze anodized aluminum transom frame with tubular jambs and threshold, fits 36x84 commercial door (diagram).
1 1

CRL

CRL-U.S. Aluminum DF800 Gear Hinge Transom Frame 39.5x126 Dark Bronze

CRL-U.S. Aluminum DF800 Gear Hinge Transom Frame 39.5x126 Dark Bronze

$1,419.92 CAD
$1,419.92 CAD
Sale Sold out
Shipping calculated at checkout.
View More Information Buy More, Save More
Item# FD31822
Shipping Weight: NA
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
View full details

Product Information

Description

Finish/Color
Black Bronze Anodized Class 1

Overview

  • 1-3/4" x 4-1/2" (44.5 x 114.3 mm) transom frame with tubular jambs — aluminum transom frame for commercial doors
  • 39-1/2" x 126" (1.0 x 3.2 m) base frame size (outside dimensions)
  • 36" x 84" (0.9 x 2.1 m) door opening — fits standard 36" x 84" commercial doors
  • Aluminum threshold is included

Complete Frame (SKU: FD31822) is built to accommodate a base 36" x 84" Gear Hinge door for a surface-mount closer. Constructed with JS455 tubular jambs and JS467 header, this commercial aluminum door frame includes door stops, weatherstrip, standard hardware, and hardware preparations for quick installation.

All fasteners, standard hardware, and hardware fabrication for frame assembly are included; customer supplies fasteners to attach frame to opening. Note: frame widths less than 39-1/2" (1.0 m) may not pass A.D.A. inspection. Ideal for contractors and building managers seeking a reinforced aluminum transom frame with tubular jambs and included threshold.

Most shipping weights are approximate and have not been verified. If the exact weight is needed to determine shipping costs before completing your order, please request this prior to submitting your order by contacting CRL Customer Service. Product images shown are of the actual product or a close representation; colors can vary depending on your computer's video card and monitor settings.


Order FD31822 today to secure a durable aluminum transom frame with tubular jambs and included threshold.
