CRL-U.S. Aluminum IG500 StormFront Butt Hinges for Concealed Closer

CRL-U.S. Aluminum IG500 StormFront Butt Hinges for Concealed Closer

$5,293.96 CAD
$5,293.96 CAD
Sale Sold out
Shipping calculated at checkout.
View More Information Buy More, Save More
Item# SF42422
Shipping Weight: NA
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
View full details

Product Information

Description

Finish/Color
Black Bronze Anodized Class 1

Overview

  • Includes standard push/pull, butt hinges, deadbolt, flush bolts, keyed cylinder, and thumbturn for concealed overhead closer
  • Accommodates 9/16" (14 mm) heat-strengthened glass with SentryGlas® Plus interlayer (glass not included)
  • Optional 10" (254 mm) bottom rail
  • FPA approved for hurricane impact installations

This CRL Custom Medium Stile Entrance Door (SKU: SF42422) is designed for commercial and residential hurricane-impact applications. It features 4-5/8" (117 mm) stiles, a 4-11/16" (119 mm) top rail, and a 7-5/16" (186 mm) bottom rail. Standard prep includes stiles for butt-hinge hardware, glass stops for 9/16" (14.2 mm) impact glazing (by others), deadbolt, flush bolts, keyed exterior cylinder, and interior thumbturn — prepped for a concealed overhead closer. These attributes make it an ideal medium stile entrance door for storm-resistant storefronts, multifamily entries, and high-traffic commercial openings.

When installing hurricane impact products, always refer to FPA guidelines.

Most shipping weights are approximate and have not been verified. If the exact weight is needed to determine shipping costs before completing your order, please request this prior to submitting your order by contacting CRL Customer Service. Product images shown are of the actual product or a close representation. Colors can vary depending on your computer's video card and how your monitor's color is adjusted.


Order SKU SF42422 or contact CRL Customer Service for a quote and glazing recommendations.
