• Clear anodized double up/over hurricane impact door frame (SKU 0P72511) with dual doors and technical header/jamb drawings.
1 1

CRL

CRL-U.S. Aluminum IG600 Clear Anodized Custom Butt Hinge Door Frame

CRL-U.S. Aluminum IG600 Clear Anodized Custom Butt Hinge Door Frame

$1,876.37 CAD
$1,876.37 CAD
Sale Sold out
Shipping calculated at checkout.
View More Information Buy More, Save More
Item# 0P72511
Shipping Weight: NA
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
View full details

Product Information

Description

Finish/Color
Clear Anodized Class 1

Overview

  • 2-1/2" x 5" (63.5 x 127 mm) butt-hinged impact up/over door frame
  • Prepped for 1-1/2" pair of butt hinges (not included)
  • Prepped for CVR panic strike (standard)
  • Includes TH811 air resistant threshold
  • Optional air/water resistant threshold available

This Custom Double Up/Over Door Frame (SKU: 0P72511) is designed for hurricane impact door applications and accommodates a pair of butt-hinged impact doors using 1-5/16" (33 mm) laminated impact glazing. Constructed with IG626/IG146/IG147 door jambs and header and specified TH811 air threshold, the frame supports surface-mount closers and is factory prepped for hinge and panic hardware for faster installation. Ideal for coastal and high-wind zones where certified hurricane impact door frames and air-resistant thresholds are required.

When installing hurricane impact products always refer to FPA Guidelines.

Most shipping weights are approximate and have not been verified. If the exact weight is needed to determine shipping costs, please request this prior to submitting your order by contacting CRL Customer Service. Product images shown are of the actual product or a close representation. Colors can vary depending on your computer's video card and monitor settings.


Contact CRL Customer Service to confirm specifications, ordering lead times, or to request a quote.
