• Clear anodized aluminum double impact door frame with center pull handles and technical header/jamb diagrams, 2-1/2" x 5".
1 1

CRL

CRL-U.S. Aluminum IG600 Clear-Anodized Up/Over Frame w/ Geared Hinge

CRL-U.S. Aluminum IG600 Clear-Anodized Up/Over Frame w/ Geared Hinge

$2,318.21 CAD
$2,318.21 CAD
Sale Sold out
Shipping calculated at checkout.
View More Information Buy More, Save More
Item# 0F72811
Shipping Weight: NA
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
View full details

Product Information

Description

Finish/Color
Clear Anodized Class 1

Overview

  • 2-1/2" x 5" (63.5 x 127 mm) geared hinged Up/Over impact door frame for surface-mount closer
  • Prepped for standard deadbolt strike
  • Includes air-resistant threshold (TH811)
  • Optional air/water-resistant threshold available

Custom Up/Over Door Frame (SKU: 0F72811) — purpose-built for a pair of geared hinged hurricane impact doors using 1-5/16" (33 mm) laminated impact glazing. Constructed with IG626 door jambs, IG626/IG100 header, IG046/IG047 stops with NP801 door stop, and TH811 air threshold. Hardware preparations include geared hinges and standard flushbolt strike, optimized for surface-mount closers.

Key differentiators: engineered specifically for hurricane impact performance, prepped for standard deadbolt installation, and available with an upgraded air/water-resistant threshold for enhanced weather protection. Ideal for coastal and high-wind environments requiring impact-rated, surface-closer-ready frames.

When installing hurricane impact products, always refer to FPA Guidelines.

Most shipping weights are approximate and have not been verified. If the exact weight is required to determine shipping costs, please request this prior to submitting your order by contacting CRL Customer Service. Product images shown are of the actual product or a close representation. Colors can vary depending on your computer's video card and monitor settings.

Need this frame for a specific project or coastal build? Contact CRL to confirm options, lead times, and threshold upgrades.
