• Double transom hurricane impact door frame, Black Bronze Anodized Class 1, 2-1/2" x 5" profile with technical drawing. SKU 0F
1 1

CRL

CRL-U.S. Aluminum IG600 Class 1 Transom Butt Hinge for 2-Door Frames

CRL-U.S. Aluminum IG600 Class 1 Transom Butt Hinge for 2-Door Frames

$3,096.34 CAD
$3,096.34 CAD
Sale Sold out
Shipping calculated at checkout.
View More Information Buy More, Save More
Item# 0F92522
Shipping Weight: NA
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
View full details

Product Information

Description

Finish/Color
Black Bronze Anodized Class 1

Overview

  • 2-1/2" x 5" (63.5 x 127 mm) butt-hinged impact transom door frame
  • Prepped for 1-1/2" pair of butt hinges (not included)
  • Prepped for standard flush-bolt strike
  • Includes air-resistant threshold; optional air/water-resistant threshold available

Custom Double Transom Door Frame — engineered for hurricane impact door installations and built to accept a pair of butt-hinged hurricane impact doors using 1-5/16" (33 mm) laminated impact glazing. Constructed from IG626/IG146/IG147 door jambs with IG667 header and IG663 seal, IG626 transom header, and TH811 air threshold. Hardware preparations include provisions for a 1-1/2" pair of butt hinges and a standard flush-bolt strike. SKU: 0F92522


For safe installation of hurricane impact products, always follow FPA guidelines.

Most shipping weights are approximate and have not been verified. If the exact weight is needed to determine shipping costs prior to placing your order, contact CRL Customer Service. Product images are actual or close representations; colors may vary by monitor.

Order this hurricane-rated transom door frame (SKU 0F92522) or contact us for a quote and technical support.
