CRL-U.S. Aluminum IG600 White KYNAR Transom Butt Hinge Door Frame

CRL-U.S. Aluminum IG600 White KYNAR Transom Butt Hinge Door Frame

$2,303.12 CAD
$2,303.12 CAD
Sale Sold out
Shipping calculated at checkout.
View More Information Buy More, Save More
Item# 0F91552
Shipping Weight: NA
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
View full details

Product Information

Description

Finish/Color
White Kynar

Overview

  • 2-1/2" x 5" (63.5 x 127 mm) butt-hinged impact transom door frame — fits single transom hurricane impact doors
  • Prepped for 1-1/2" pair of butt hinges (hinges not included)
  • Prepped for standard flush-bolt / deadbolt strike
  • Includes air-resistant TH811 threshold; optional air/water-resistant threshold available

This Custom Single Transom Door Frame (SKU: 0F91552) is engineered for hurricane impact performance and built to accept 1-5/16" (33 mm) laminated impact glazing. Constructed from IG626/IG146/IG147 door jambs with IG667 header and IG663 seal, plus IG626 transom header and TH811 air threshold. Hardware preparations include provisions for a surface-mount closer, 1-1/2" pair of butt hinges, and a standard deadbolt strike. Ideal for contractors and installers specifying hurricane impact transom door frames and air-resistant thresholds.


When installing hurricane impact products, always refer to FPA guidelines.

Most shipping weights are approximate and have not been verified. If the exact weight is needed to determine shipping costs, please request this prior to submitting your order by contacting CRL Customer Service. Product images shown are of the actual product or a close representation. Colors can vary depending on your computer's video card and monitor settings.


Need a quote or technical details for installation? Contact CRL Customer Service to order or request exact shipping weight and available threshold options.
