CRL-U.S. Aluminum Narrow Vertical Door Mullion, Black Bronze, Custom
CRL-U.S. Aluminum Narrow Vertical Door Mullion, Black Bronze, Custom
Regular price
$0.00 CAD
Regular price
Sale price
$0.00 CAD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Item# M12DUC
Shipping Weight: NA
Shipping Limitations: No UPS - Common Carrier Only
Unit of Measure: Stock Length
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Shipping Weight: NA
Shipping Limitations: No UPS - Common Carrier Only
Request A Quote For A Shipping Rate
Minimum Order Quantity: 1Unit of Measure: Stock Length
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Description
Finish/Color
Black Bronze Anodized
Glazing Thickness
1/2 in. (12 mm)
Height
1-1/2 in. (38 mm)
Width
2 in. (51 mm)
Overview
- Only 1-1/2" (38 mm) wide profile
- No exposed fasteners for a clean, architectural finish
- Cladding available in five architectural finishes
Create sleek interior office fronts and narrow-profile storefronts using 1/2" (12 mm) fully tempered glass with slim jambs and vertical mullions. The M12DUC mechanical clamping system integrates with DRS Rails and Vertical Weatherstiles to deliver higher performance than typical butt-glazed assemblies. Improved mechanical weatherstile design simplifies installation and reduces visible hardware for a minimalist aesthetic. Offered in 120" (3.05 m) stock lengths or special-ordered to project-specific lengths. Available finishes: satin anodized, black bronze anodized, polished stainless steel, brushed stainless steel, and polished brass cladding — ideal for commercial interior glass partitions and narrow mullion storefront systems.
SKU: M12DUC
Order the M12DUC narrow-profile glass mullion system today to streamline installation and achieve a clean, modern office storefront. Contact CRL for availability and custom lengths.
