CRL-U.S. Aluminum Series 250 Clear Anodized 36x84 Narrow Stile Door
Item# DC21511
Shipping Weight: NA
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Shipping Weight: NA
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Finish/Color
Clear Anodized Class 1
- 9-1/2" (241 mm) bottom rail available to comply with A.D.A. and Title 24 applications
- Custom fabricated to accept optional hardware applications
- Includes standard push/pull, hanging hardware, MS hookbolt lock, and two keyed-alike cylinders
- Accommodates 1/4" (6 mm) tempered glass; optional 1" (25 mm) tempered insulating unit available (glass not included)
This Custom Narrow Stile Entrance Door (SKU: DC21511) features 2" (51 mm) stiles, a 2-1/8" (54 mm) top rail, and a 3-3/16" (81 mm) bottom rail. Standard design includes stiles for butt hinge hardware and glass stops sized for 1/4" (6 mm) tempered glass (by others). Built for commercial entrances, the door is ready for custom fabrication to support a wide range of optional hardware—ideal when you need a narrow stile entrance door that accepts specialty locks and commercial push/pull sets.
Important: included protruding hardware (handles, pivots, etc.) is boxed separately to prevent transit damage and must be installed by the customer. Note that door widths under 36" (914 mm) may not pass A.D.A. inspection.
Most shipping weights are approximate. If you need an exact weight to determine shipping costs before ordering, contact CRL Customer Service. Product images are of the actual product or a close representation; colors may vary with monitor settings.
Order SKU DC21511 or contact us for custom hardware options and ADA-compliant configurations.
BIM Objects - rvt
