CRL-U.S. Aluminum Series 250 Clear Anodized Narrow Stile Geared Hinge

• Includes Standard Push/Pull, hanging hardware, MS Hookbolt lock, and two keyed‑alike cylinders — secure commercial door hardware
• Accepts 1/4" (6 mm) tempered glass or optional 1" (25 mm) tempered insulating unit (glass not included)
• 9-1/2" (241 mm) bottom rail available to meet A.D.A. and Title 24/21 applications for accessible entrances
• Custom fabricated to accept a wide range of optional hardware applications and commercial storefront fittings

Custom Narrow Stile Entrance Door (SKU: DC21811) — Built with 2" (51 mm) stiles, a 2-1/8" (54 mm) top rail, and a 3-3/16" (81 mm) bottom rail. Standard preparations include stiles for Gear Hinge hardware and glass stops for 1/4" (6 mm) tempered glass (by others). Designed for custom fabrication to accommodate optional commercial door hardware.

Included protruding hardware (handles, pivots, etc.) is boxed separately and must be installed by the customer to prevent transit damage. Note: door widths under 36" (914 mm) may not pass A.D.A. inspection.

Order SKU DC21811 now to get a custom narrow stile commercial entrance door ready for tempered or insulating glass — contact us for lead times and hardware options.
