CRL-U.S. Aluminum Series 400 KYNAR Geared-Hinge Offset-Hung Door

• Includes standard panic pull and hanging hardware
• Selected panic hardware and one cylinder ordered separately
• Accommodates 1/4" (6 mm) tempered glass; optional 1" (25 mm) tempered insulating unit compatible (glass not included)
• 6-1/2" (165 mm) bottom rail
• Custom fabricated to accept optional hardware applications

This Custom Medium Stile Entrance Door (SKU: DZ41871) is engineered for commercial storefronts and institutional entrances. Construction details: 3-1/2" (89 mm) stiles, 3-3/16" (81 mm) top rail, and a 6-1/2" (165 mm) bottom rail. Standard features include stiles prepped for Gear Hinge hardware and glass stops sized for 1/4" (6 mm) tempered glass supplied by others. Built for custom fabrication to accept a wide range of optional hardware—ideal for specifying panic exit devices, commercial-grade pivots, and ADA-aware installations.

Note: Included protruding hardware (handles, pivots, etc.) ships boxed separately and must be installed by the customer to avoid transit damage. Doors under 36" (914 mm) wide may not meet ADA inspection requirements.

Order SKU DZ41871 today or contact us for custom hardware integration and shipping weight details.
