CRL-U.S. Aluminum Series 550 Wide Stile Butt Hinge for Entrance Doors
CRL-U.S. Aluminum Series 550 Wide Stile Butt Hinge for Entrance Doors
Regular price
$1,572.96 CAD
Regular price
Sale price
$1,572.96 CAD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Item# DC51571
Shipping Weight: NA
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Shipping Weight: NA
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Description
Finish/Color
Custom Kynar
Overview
- 7" (178 mm) Bottom Rail (standard)
- 10" (254 mm) Bottom Rail available to comply with A.D.A. and Title 24 applications
- Custom fabricated to accept optional hardware applications
- Includes standard push/pull, hanging hardware, MS hookbolt lock, and two keyed‑alike cylinders
- Accommodates 1/4" (6 mm) tempered glass; optional 1" (25 mm) tempered insulating glass unit available (glass not included)
This Custom Wide Stile Entrance Door (SKU: DC51571) features 5-1/2" (140 mm) stiles, a 6" (152 mm) top rail, and a 7" (178 mm) bottom rail. Built for storefront and commercial applications, the heavy-duty wide stile design is ready for butt hinge hardware and glass stops for 1/4" tempered glass (by others). Custom fabrication options support a wide range of optional hardware for ADA-compliant entrances and Title 24 storefronts.
Customer-installed protruding hardware (handles, pivots, etc.) is boxed separately to prevent transit damage. Note: door widths under 36" (914 mm) may not meet A.D.A. inspection requirements.
Order SKU DC51571 today or contact us for custom hardware and glazing options.
Specifications
BIM Objects - rvt
