CRL-U.S. Aluminum KYNAR Series 250 Narrow Stile Offset Pivot Doors
CRL-U.S. Aluminum KYNAR Series 250 Narrow Stile Offset Pivot Doors
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Item# CD22271
Shipping Weight: NA
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: Pair
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Shipping Weight: NA
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: Pair
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Description
Finish/Color
Custom Kynar
Overview
- Accommodates 1/4" (6 mm) tempered glass; optionally accepts 1" (25 mm) tempered insulating glass unit (glass sold separately)
- 9-1/2" (241 mm) ADA-compliant bottom rail
- Custom fabricated to accept a wide range of optional hardware applications
- Includes active and inactive leaves with all standard hardware
This CRL Custom Narrow Stile Entrance Door features 2" (51 mm) stiles, a 2-1/8" (54 mm) top rail, and a 9-1/2" (241 mm) bottom rail. Designed for commercial storefront and office entry use, it ships ready for offset pivot hardware and includes glass stops for 1/4" (6 mm) tempered glass (glass by others). The narrow stile profile and custom-fabrication option make this door ideal for retrofit and custom hardware installations.
Handles, pivots, and other protruding hardware are boxed separately to prevent transit damage and must be installed by the customer.
SKU: CD22271 — For custom quotes and lead times, contact CRL or add to your cart to begin configuring your narrow stile entrance door.
Specifications
BIM Objects - rvt
