CRL-U.S. Series 250 36x84 Black Anodized Narrow Stile Door Butt Hinge

• Includes standard panic pull, hanging hardware, concealed vertical rod panic hardware, and one cylinder
• Fits 1/4" (6 mm) tempered glass; optional 1" (25 mm) tempered insulating glass unit available (glass not included)
• 9-1/2" (241 mm) bottom rail installed to comply with A.D.A. requirements
• Custom fabricated to accept a wide range of optional hardware applications

CRL Custom Narrow Stile Entrance Door (SKU: CZ21522) features 2" (51 mm) stiles, a 2-1/8" (54 mm) top rail, and a 9-1/2" (241 mm) bottom rail. The door includes stiles prepped for butt hinge hardware and glass stops sized for 1/4" (6 mm) tempered glass (provided by others). It is ready for custom fabrication to add optional hardware such as concealed vertical rod panic devices—making it ideal for commercial, retail, and institutional narrow stile entrance applications.

Note: Protruding hardware (handles, pivots, etc.) is boxed separately and must be installed on site to avoid transit damage. Door widths under 36" (914 mm) may not meet A.D.A. inspection requirements.

Order the CRL CZ21522 narrow stile entrance door now or contact us for custom hardware options and ADA guidance.
