CRL
CRL-U.S. Series 250 Blk Anod Alum Bronze Geared Hinge Pair - Panic Ready
CRL-U.S. Series 250 Blk Anod Alum Bronze Geared Hinge Pair - Panic Ready
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Item# DZ22922
Shipping Weight: NA
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: Pair
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Shipping Weight: NA
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: Pair
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Description
Finish/Color
Black Bronze Anodized Class 1
Overview
- Custom made to your size specifications (SKU: DZ22922)
- Includes standard panic pull and hanging hardware
- Panic hardware and one cylinder must be ordered and added separately
- Accommodates 1/4" (6 mm) tempered glass; optional 1" (25 mm) tempered insulating unit available (glass not included)
- 9-1/2" (241 mm) bottom rail option to comply with A.D.A. and Title 24 applications
- Custom fabricated to accept a wide range of optional hardware applications
This Custom Narrow Stile Entrance Door is engineered with 2" (51 mm) stiles, a 2-1/8" (54 mm) top rail, and a 3-3/16" (81 mm) bottom rail. Standard features include stiles prepped for Gear Hinge hardware and glass stops sized for 1/4" (6 mm) tempered glass (provided by others). The door is ready for custom fabrication for additional optional hardware applications.
Customer-installed protruding hardware (handles, pivots, etc.) is boxed separately to prevent transit damage. Note: door widths under 36" (914 mm) may not meet A.D.A. inspection requirements. Panic hardware and one cylinder are ordered separately.
Specifications
BIM Objects - rvt
