CRL-U.S. Series 550 36x84 Offset Pivot Entrance Door Right-Hand Latch
Item# DE51122R360090
Shipping Weight: NA
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Shipping Weight: NA
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Finish/Color
Black Bronze Anodized Class 1
- Includes standard push/pull, hanging hardware, MS hookbolt lock, and two keyed‑alike cylinders — ideal for commercial storefronts
- Accepts 1/4" (6 mm) tempered glass; optional 1" (25 mm) tempered insulating unit also fits (glass sold separately)
- 9‑1/2" (241 mm) bottom rail installed to comply with A.D.A. requirements
This Standard Wide Stile Entrance Door features 5" (127 mm) stiles, a 5‑1/2" (140 mm) top rail, and a 9‑1/2" (241 mm) ADA bottom rail. Built with stiles for offset pivot hardware and glass stops sized for 1/4" (6 mm) tempered glass (by others), the door is ready for custom fabrication and a wide range of optional hardware. 1" (25 mm) glass stops are the only optional stop available on standard doors.
SKU: DE51122R360090
Most shipping weights are approximate and have not been verified. If an exact weight is required to determine shipping costs, request this prior to ordering by contacting CRL Customer Service. Product images are actual products or close representations; colors may vary by monitor and settings.
Need pricing or a quote? Contact CRL Customer Service to order or request more details.
BIM Objects - rvt
