- Makes it a One Person Job Of Transferring Glass Between Upright and Flat
- 300 Lbs. (135 kg) Lifting Capacity
- Reduces the Risk of Glass Damage
- Dual Vacuum System CAT. NO. E010DVS
- Flat Lift Model CAT. NO. FL2HV11DCS
- Closed Cell Foam Pad Rings CAT. NO. FRHV11
- Removable Control Pendant CAT. NO. E09RP Product images shown are of the actual product or a close representation. Colors can vary depending on your computer's video card and on how your monitor's color is adjusted.
The
CRL Wood's Powr-Grip® Manual Tilter 300
is the most economical method of tilting Glass. The frame automatically locks into the upright position for transporting glass. Conveniently placed handle helps keep the operator in control of the load at all times. Only five seconds are required to apply full vacuum to the glass and 5 seconds to release.
Standard Pad Spread
11" x 23" (280 x 584 mm)
Number/Size of Pads
2/10" (254 mm) Diameter Lipped
Lifting Capacity
300 Lbs. (135 kg) (On smooth, non-porous surfaces. Please contact us for recommendations on other surfaces.)
Unit Weight
51 Lbs. (24 kg)
Standard Operating Power
12V DC, 10 AMP (Other voltages available)
Apply/Release
5/5 sec. (approx)
Load Movement
Manual Tilt, 90 Degrees Between Upright and Flat
Standard Features
Low Vacuum Warning Light
Vacuum Gauge
Vacuum Line Filter
Vacuum Reserve Tank
On-Board Battery and Charger
Battery Energy Gauge
Available Options
Dual Vacuum System CAT. NO. E010DVS
Flat Lift Model CAT. NO. FL2HV11DCS
Closed Cell Foam Pad Rings CAT. NO. FRHV11
Removable Control Pendant CAT. NO. E09RP
Product images shown are of the actual product or a close representation. Colors can vary depending on your computer's video card and on how your monitor's color is adjusted.
