CRL50 Series Two Panel Telescoping Ceiling Mount Kit - Right Stacking Direction

• Telescoping Operation for 5/16" or 3/8" (8 or 10 mm) Tempered Glass Doors
• Use Monolithic Tempered Glass
• Can Accommodate Doors Weighing Up to 176 Pounds (80 kg), Maximum Door Width of 40-3/8" (1025 mm)

There are eight configurations of CRL50 Series Kits for telescoping 5/16" to 3/8" (8 to 10 mm) tempered glass doors. These Kits provide telescoping operation where two panels slide in the same direction and stack away together. All come with everything you need (except the tempered glass) to complete the installation. Kits are available in a satin anodized finish, with an option for powder paint or cladding in any architectural finish desired. Contact Technical Sales for Commercial Products for kit selection or installation assistance.


NOTE: Laminated glass should not be used with the CRL50 System.


Product Warning:

STRUCTURAL DISCLAIMER - All customers who in any way utilize this product are solely responsible to consult a structural engineer to determine the suitability of the product for the intended use and site conditions. All installers must be qualified and have professional knowledge about compliance with local, state and federal regulations, safety factors, and the appropriate choice of fixing material and procedures.
