CRL 316 Brushed Stainless Steel Radius Base Glass Clamp 1/2 & 9/16 in
CRL 316 Brushed Stainless Steel Radius Base Glass Clamp 1/2 & 9/16 in
Regular price
$50.54 CAD
Regular price
Sale price
$50.54 CAD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Item# ZP712BS
Shipping Weight: 13.76 Ounces
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Shipping Weight: 13.76 Ounces
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Description
Base Type
Radius
Depth
1-7/32 in. (31 mm)
Finish/Color
Brushed Stainless Steel
Material
316 Stainless Steel
Overview
- SKU: ZP712BS
- Radius base for use with Round Schedule 40 1.9" (48 mm) diameter P7 series posts — ideal for glass balustrades and guardrail infill
- 316 grade stainless steel for marine and exterior applications
- Requires ZBOLT38 to attach to post (sold in packs of 10)
SPECIFICATIONS
Glass Thickness: 1/2" (12 mm) and 9/16" (13.52 mm)
Base Design: Flat or Radius
For Use With: 1.9" (48 mm) diameter round tubing (Schedule 40)
Material: 316 grade stainless steel
Glass Fabrication: One 7/8" (22 mm) diameter finger notch required. The included steel pin must be used for guardrail infill applications to support the glass.
Includes: Rubber gaskets and steel pin
Stainless Steel Advisory:
Although stainless steel is highly corrosion resistant, it is not completely rust- or stain-proof. CRL recommends periodic maintenance to preserve the factory finish. See the Stainless Steel Disclaimer in the Technical References for care details.
Order ZP712BS radius base for 1.9" P7 posts today to complete your 316 stainless glass balustrade or guardrail installation.
