CRL 316 Polished Stainless Radius Base Clamp for 1/2" and 9/16" Glass

• Radius Base for Use with Round Schedule 40 1.9" (48 mm) Diameter P7 Series Posts
• 316 Grade Stainless Steel
• Requires ZBOLT38 to attach to post (sold in packs of 10)

Glass Thickness: 1/2" (12 mm) and 9/16" (13.52 mm)

Base Design: Flat or Radius

For Use With: 1.9" (48 mm) Diameter Round Tubing.

Material: 316 Grade Stainless Steel

Glass Fabrication: One 7/8" (22 mm) diameter finger notch is required. The included steel pin must be used for guard rail infill applications to support the glass.

Includes: Rubber Gaskets and Steel Pin

Product images shown are of the actual product or a close representation. Colors can vary depending on your computer's video card and on how your monitor's color is adjusted.

Although Stainless Steel is resistant to corrosion, it is not rust or stain proof. CRL recommends periodic maintenance to help maintain its factory finish. For more information, view the Stainless Steel Disclaimer found in the Technical References section below.
