CRL 690 Brushed SS Drop-Ceiling Sliding Door Kit w/ Fixed Panel

• Kits intended for 3/8" to 1/2" (10 to 12 mm) monolithic tempered glass
• Supports properly installed door weights up to 330 pounds (150 kg)
• Rollers provide up to 1/4" (6 mm) vertical adjustment for post‑installation door alignment
• Track length: 118" (3 m)
• Designed for frameless sliding glass doors and commercial sliding door hardware applications

CRL 690 Series Sliding Door Kits are available in wall mount, ceiling mount, and drop ceiling mount models, with or without a sidelite and with or without the optional "Softbrake" braking system. Kits include all necessary hardware except tempered glass and pull hardware. Finish options include satin anodized, brushed stainless anodized, and matte black, with special‑order cladding or powder paint finishes available. For assistance with kit selection or installation, contact CRL Technical Sales for Commercial Products. SKU: CRL6901DBSA.

Minimum sliding panel width: 23-5/8" (600 mm). Existing CRL690 Series installations can be upgraded to CRL695 Series using CRL695SBK Softbrake kits (minimum door panel width 34-1/4" / 870 mm).

Kit Contains:

• 118" (3 m) CRL4930EXT Track kit
• 1 set CRL6939 top hangers
• 1 set CRL6942 roller stops
• 1 set CRL4937 end caps
• 1 set CRL2945 door edge guards
• 1 set CRL290TF top track insert fasteners
• 1 each CRL bottom guide

Order the CRL 690 Series sliding door kit (CRL6901DBSA) for a durable, adjustable frameless sliding glass door solution — contact sales to buy or request a quote today.
