CRL 690 Satin Anodized Glass Sliding Door - Wall/Ceiling Kit

• Kits intended for 3/8" to 1/2" (10 to 12 mm) tempered glass
• Supports properly installed sliding doors up to 330 lb (150 kg)
• Rollers offer up to 1/4" (6 mm) vertical adjustment for post-installation alignment
• Track length: 118" (3 m)
• Designed for monolithic tempered glass

CRL 690 Series Sliding Door Kits (SKU: CRL6901) are commercial-grade tempered glass sliding door kits available in wall mount, ceiling mount, and drop ceiling mount configurations. Choose models with or without a sidelite and with or without the Softbrake soft-close braking system. Kits include all hardware except the tempered glass and pull hardware. Available finishes: satin anodized, brushed stainless anodized, and matte black; special-order cladding or powder-coating in many architectural finishes is available. Contact CRL Technical Sales for commercial sliding door kit selection or installation assistance.

Minimum sliding panel widths: 30-7/8" (785 mm) for single-direction control; 42-1/2" (1080 mm) for bi-directional control. Existing CRL690 Series installations can be upgraded with replacement kits.

Kit Contains:

• 118" (3 m) CRL4931EXT track kit
• 118" (3 m) CRL6979A bottom channel
• Glazing vinyl for 3/8" to 1/2" (10 to 12 mm) glass
• 1 set CRL6939 top hangers
• 1 set CRL6942 roller stops
• 1 set CRL4938 end caps
• 1 CRL2940 bottom guide
• 1 set CRL2945 door edge guards
• 1 set CRL290TF top track insert fasteners

Order the CRL6901 commercial tempered glass sliding door kit today to simplify installation and achieve a clean, modern glass door solution.
