CRL 695 Stainless Anodized Ceiling-Mount Sliding Door Kit w/ Softbrake

• Kits intended for 3/8" to 1/2" (10 to 12 mm) monolithic tempered glass
• Supports properly installed door weight up to 330 lb (150 kg) — commercial-grade load capacity
• Rollers provide up to 1/4" (6 mm) vertical adjustment for precise door alignment after installation
• 118" (3 m) aluminum track length included for standard single-panel and bypass installations
• Available with optional Softbrake braking system for controlled, quiet closing

CRL 690 Series Sliding Door Kits — models include wall mount, ceiling mount, and dropped ceiling mount, with or without sidelite and with or without the Softbrake. Kits include all hardware except tempered glass and pull hardware. Finishes: satin anodized, brushed stainless anodized, and matte black; special-order cladding or powder paint available in many architectural finishes. For kit selection or installation assistance, contact CRL Technical Sales for Commercial Products. SKU: CRL695DBSA.

Minimum sliding panel width: 34-1/4" (800 mm) for controlled single- or bi-directional operation.

Kit contains:

• 118" (3 m) CRL4933EXT track kit
• 118" (3 m) CRL6979A bottom channel
• Glazing vinyl for 3/8" to 1/2" (10 to 12 mm) tempered glass
• 1 set CRL6939 top hangers
• 1 set CRL6942 roller stops
• 1 CRL2940 bottom guide
• 1 set CRL2945 door edge guards
• 1 set CRL2929 dropped ceiling adapter bracket
• 1 CRL695SBK Softbrake kit
