CRL 695 Brushed Stainless Sliding Door Kit w/ Fixed Panel & Softbrake

• Kits intended for 3/8" to 1/2" (10 to 12 mm) monolithic tempered glass
• Accommodates properly installed door weights up to 330 pounds (150 kg)
• Rollers provide up to 1/4" (6 mm) vertical adjustment for post-installation door alignment
• Track length: 118" (3 m)
• Use monolithic tempered glass

CRL 690 Series Sliding Door Kits (SKU: CRL6951BSA) — commercial sliding glass door kits engineered for heavy-duty tempered glass applications. Available in wall-mount, ceiling-mount, and dropped-ceiling models, with optional sidelite and optional Softbrake braking system. Kits include all hardware except the tempered glass and pull hardware. Finish options: satin anodized, brushed stainless anodized, and matte black; special-order cladding or powder paint finishes available. Contact CRL Technical Sales for commercial kit selection or installation assistance.

• Minimum sliding panel width: 34-1/4" (800 mm) for controlled single- or bi-directional operation

• 118" (3 m) CRL4931EXT track kit
• 118" (3 m) CRL6979A bottom channel
• Glazing vinyl for 3/8" to 1/2" (10 to 12 mm) glass
• 1 set CRL6939 top hangers
• 1 set CRL6942 roller stops
• 1 each CRL2940 bottom guide
• 1 set CRL2945 door edge guards
• 1 set CRL2929 dropped ceiling adapter bracket
• 1 each CRL695SBK Softbrake kit

Shop the CRL 690 Series for a high-capacity, adjustable sliding glass door solution with optional Softbrake—contact us to order or request installation support.
