CRL 695 Matte Black Sliding Door Hardware Kit w/ Softbrake
CRL 695 Matte Black Sliding Door Hardware Kit w/ Softbrake
Regular price
$2,238.12 CAD
Regular price
Sale price
$2,238.12 CAD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Item# CRL695MBL
Shipping Weight: NA
Shipping Limitations: No UPS - Common Carrier Only
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Shipping Weight: NA
Shipping Limitations: No UPS - Common Carrier Only
Request A Quote For A Shipping Rate
Minimum Order Quantity: 1Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Description
Finish/Color
Matte Black
Glazing Thickness
3/8 in. To 1/2 in. (10 mm To 12 mm)
Track Length
118 in. (3000 mm)
Overview
- For 3/8" to 1/2" (10 to 12 mm) tempered glass — monolithic tempered glass recommended
- Supports doors up to 330 lb (150 kg) when properly installed — heavy-duty commercial sliding door hardware
- Rollers provide up to 1/4" (6 mm) vertical adjustment for precise door alignment after installation
- 118" (3 m) track length included
- Minimum sliding panel width: 34-1/4" (800 mm) for controlled single- or bi-directional operation
CRL 690 Series Sliding Door Kits are available wall mount, ceiling mount, and drop ceiling mount. Choose models with or without a sidelite and with or without the optional "Softbrake" braking system. Kits include all hardware except tempered glass and pull hardware. Finishes: satin anodized, brushed stainless anodized, and matte black; special-order cladding or powder coat finishes available. For kit selection or installation assistance, contact CRL Technical Sales for Commercial Products. SKU: CRL695MBL.
Kit Contains:
- 118" (3 m) CRL4933EXT track kit
- 118" (3 m) CRL6979A bottom channel
- Glazing vinyl for 3/8" to 1/2" (10 to 12 mm) glass
- 1 set CRL6939 top hangers
- 1 set CRL6942 roller stops
- 1 each CRL2940 bottom guide
- 1 set CRL2945 door edge guards
- 1 set CRL2929 dropped ceiling adapter bracket
- 1 each CRL695SBK Softbrake kit
Durable, adjustable, and designed for commercial tempered glass sliding door installations — order the CRL695MBL sliding door kit today or contact us for assistance.
