CRL Aluminum Offset Right-Hand Pivot Set, 3/32" Recess for Glass Doors
CRL Aluminum Offset Right-Hand Pivot Set, 3/32" Recess for Glass Doors
Regular price
$36.91 CAD
Regular price
Sale price
$36.91 CAD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Item# 0P41RHA
Shipping Weight: 1.0 Pounds
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: Set
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Shipping Weight: 1.0 Pounds
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: Set
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Description
Bottom Door Clearance Adjustment
1/8 in. (3.2 mm)
Door Weight
125 lbs. (56.7 kg)
Entry Trim
8500LV02628,8500LV01628,8500EL02628,8500EL01628
Field Sizeable
Yes
Finish/Color
Aluminum
Handing
Right Hand
Material
Aluminum
Pivot Series
OP41
Pivot Set
Yes
Pivot Style
3/32 in. Recess (2 mm Recess)
Pivot Type
Offset
Recommended Door Type
Aluminum Store Front
Overview
- 1/8" (3.2 mm) vertical adjustment
- Diecast aluminum construction for commercial doors
- Suitable for aluminum frames and doors weighing up to 125 lbs. (57 kg)
- Handed — not reversible (left or right hand pivot sets available)
- Compatible with Pittco® and PPG® doors
CRL Offset Pivot Sets are heavy-duty commercial door pivot sets with machined and diecast components designed for aluminum frame doors. Each box contains the pivot set, door fasteners and anchors, and illustrated dimensions for easy selection. Available in satin aluminum and dark bronze finishes. One set per package. SKU: 0P41RHA
