CRL Black Powder-Coated 3-Panel XOX Bypass Overhead Sliding Door

• Silent moving four-roller carriage assemblies for smooth overhead track operation
• Custom built in eight standard sliding configurations and eight standard bi-fold configurations
• For use with 3/8" or 1/2" (10 or 12 mm) tempered glass
• Available in six architectural finishes; custom finishes available on special order

The CRL Overhead Track Sliding and Bi-Fold Door Systems (SKU: 0TS203BL) deliver reliable, low-noise performance for commercial and residential glass door installations. Their universal track and roller design supports sliding, half-panel bi-fold, or full-panel bi-fold configurations and is optimized for tempered glass panels. Each system is custom built to your specified opening size, glass thickness, and locking hardware.

Our Cat. No. 0TCA top roller carriage assemblies adjust easily for height and alignment. The compact carriage design lets the top track and door rail widths match for a clean sight line; a pile weatherstrip fills the gap between track and rail. An optional recessed 0TBR Series guide channel is included with each system for improved security and performance.

CRL overhead track sliding door systems are available in eight standard configurations. Each sliding panel is suspended by two Cat. No. 0TCA carriage assemblies. Maximum panel weight: 225 lbs. (102 kg). Maximum panel width: 72" (1.83 m). Minimum panel width: 25" (635 mm). Available by custom order only. Standard with 4" (102 mm) square rails; 4", 6", or 10" (102, 152, or 254 mm) rail combinations available. Most orders can be fabricated in five business days at our Los Angeles, California manufacturing facility. Contact CRL Technical Sales for additional information and installation guidance.


Contact CRL to quote your custom overhead track sliding or bi-fold door system today.
