CRL Brushed Nickel Junior Traditional Style Fixed Panel U-Clamp
Item # UC66BN
$39.71
CAD
Finish (3)
-
Oil Rubbed Bronze -
Brushed Nickel -
Polished Chrome
Overview
| SKU | UC66BN |
|---|---|
| Sold As | 1 Each |
| Finish/Color | Brushed Nickel |
| Glazing Thickness | 1/4 in. (6 mm) |
| Material | Brass |
| Mounting Type | Wall Mount |
Description
- For 1/4" (6 mm) Thick Glass Only
- Use Monolithic Tempered Glass
- Used to Secure Fixed Panels of Glass for Frameless Shower Enclosures
- Solid Brass
- A Nice Option to More Traditional U-Channel, in that the Clamps Help the Appearance of an 'All-Glass' Look
- Glass Fabrication Required to Accommodate Clamps
CRL Junior Traditional Style Fixed Panel U-Clamp mounts directly to the wall, ceiling or floor to secure vertical fixed glass panels. The corners are rounded off. Clearance between the glass and wall is from 5/32" to 3/16" (4 to 5 mm). Clear Silicone can be used to provide a clean, water resistant seal.
SPECIFICATIONS:
Glass Thickness: 1/4" (6 mm)
Material: Solid Brass
Includes: Mounting Screw and Clear Gaskets
Hole Diameter Required: 5/8" or 3/4" (16 or 19 mm)
