CRL 24 in Brushed Stainless Steel Ladder Door Pull, Single-Sided

CRL 24 in Brushed Stainless Steel Ladder Door Pull, Single-Sided

$247.89 CAD
$247.89 CAD
Sale Sold out
Shipping calculated at checkout.
View More Information Buy More, Save More
Item# 24LPSBS
Shipping Weight: 4.123 Pounds
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
View full details

Product Information

Description

Diameter
1-1/4 in. (32 mm)
Finish/Color
Brushed Stainless Steel
Glazing Thickness
3/8 in. To 3/4 in. (10 mm To 19 mm)
Material
Stainless Steel
Mounting Center To Center
12 in. (305 mm)
Mounting Hole Diameter
5/8 in. (16 mm)
Mounting Type
Single Sided
Overall Length
24 in. (610 mm)
Style Washers
No

Overview

  • Five sizes: 24" to 48" overall height (610 mm to 1.22 m)
  • Finishes: Brushed Stainless, Polished Stainless, Matte Black
  • Custom lengths, designs, and finishes available on special order — custom pull order forms
  • Materials: 304 grade stainless steel tubing for corrosion resistance and commercial durability

CRL straight-style ladder pulls (SKU: 24LPSBS) are designed for commercial glass and wood doors. They include two mid-posts and mounting fasteners for back-to-back installation on tempered glass 3/8" to 3/4" (10–19 mm) thick. Fasteners for 1-3/4" (44 mm) wood or aluminum doors are ordered separately. Custom ladder pulls can be specified with additional mid-posts for extra support; maximum mid-post spacing is 72" (1.83 m).


SPECIFICATIONS:
Compatible with 3/8" to 3/4" (10–19 mm) thick tempered glass, or 1-3/4" (44 mm) thick aluminum or wood doors.


CONSTRUCTION:
1-1/4" (32 mm) diameter 304 grade stainless steel tubing.


GLASS FABRICATION:
Requires two 5/8" (16 mm) diameter holes in glass.


NOTE: View our back-to-back ladder pulls in all available sizes and finishes.


Most shipping weights are approximate and have not been verified. If exact weight is required to determine shipping costs, contact CRL Customer Service before submitting your order. Product images are representative; actual colors may vary by monitor settings.

Stainless Steel Advisory:

Although 304 stainless steel resists corrosion, it is not rust- or stain-proof. Periodic maintenance is recommended to preserve the factory finish. See the Stainless Steel Disclaimer in Technical References for care instructions.


Designed for commercial glass doors — order a custom finish or additional mid-posts for heavy-traffic installations.

<
