CRL Brushed Stainless 3-Way Glass Spider Fitting - Post/Column Mount
CRL Brushed Stainless 3-Way Glass Spider Fitting - Post/Column Mount
Regular price
$167.29 CAD
Regular price
Sale price
$167.29 CAD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Item# PMH3BS
Shipping Weight: 1.83 Pounds
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Shipping Weight: 1.83 Pounds
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Description
Overview
- For use with glass up to 1-1/16" (27 mm)
- Complete with hardware to mount to post or column
- Glass attachments are sold separately
- Use monolithic tempered glass
This CRL Three Arm Fitting (SKU: PMH3BS) attaches three inline glass panels to a structural center post where they meet at a soffit corner. Includes a 16 x 99.5 mm (3-7/8") stainless steel threaded stud with three matching nuts and washers for secure center-post glass mounting. Replacement stud set available for easy maintenance. This durable three-arm glass fitting is ideal for frameless glass railing and glass partition installations using monolithic tempered glass.
For companion fittings, use Cat. No. PMH1LBS, PMH1LPS, PMH2VBS, PMH2BVPS, PMH4BS, or PMH4PS.
Stainless Steel Advisory:
Although stainless steel is corrosion resistant, it is not completely rust- or stain-proof. CRL recommends periodic maintenance to preserve the factory finish. See the Stainless Steel Disclaimer in Technical References for care details.
Order PMH3BS today or contact CRL for technical support and replacement stud sets.
