CRL 3/4 in Brushed Stainless Steel U-Channel Cap for Glass

• For 3/4" (19 mm) glass
• Protects glass edge
• Secures glass panels together
• Available in two architectural finishes
• Use with monolithic tempered glass

CRL U-Channel Cap is a 304 stainless steel U-channel designed to protect the edge of 3/4" (19 mm) glass and secure glass panels together in cap railing installations. Standard material is 304 stainless alloy at 18 gauge; Alloy 316 is available by special order. Designed as a glass edge protector and panel retention channel for architectural glass applications. SKU: GRUC7BS10.


NOTE: These U-Channels are not designed to be used as a top rail for guard rail applications.

NOTE: When used with 3/4" (19 mm) glass, use the proper cap rail vinyl and Cat. No. 95CBL Silicone to secure the glass.

Please contact CRL Technical Sales Department for additional information or a quote.

SPECIFICATIONS:
Material: 304 Stainless Steel (316 available special order)
Thickness: .050" (1.27 mm) / 18 gauge
Stock Length: 10'-0" (3.05 m)
Typical Uses: Protects the edge of the glass and secures glass panels together in cap railing installations — ideal as a glass edge protector and U-channel for 3/4" tempered glass.

Product Warning:

SS channel or bar must ship common carrier only; no UPS. Cannot be cut-to-size.

Stainless Steel Advisory:
