CRL Dark Bronze Jackson® Locking Flat Lever Outside Trim with Night Latch Function
Item # 9500LVNL02313
Finish (2)
-
Dark Bronze -
Aluminum
Overview
| SKU | 9500LVNL02313 |
|---|---|
| Sold As | 1 Each |
| Door Thickness | 1-3/4, 2, 2-1/4, & 2-3/8 |
| Finish/Color | Dark Bronze |
| Handing | Non Handed |
| Height | 7-7/16 |
| Lever Length | 4-1/4 |
| Lever Style | Flat |
| Material | Aluminum |
| Projection | 37988 |
| Series | 1295 and 2095 |
| UL Listed | Yes |
| Width | 1-3/4 |
Description
- For Use with Models 1295 and 2095 Rim Panic Exit Devices
- Non-Handed, Field Reversible
- Fits Narrow, Medium, and Wide Stile Aluminum, Wood or Hollow Metal Doors
- Designed for Use with CRL Jackson® 1200 and 20 Series Panic Exit Devices
The CRL Jackson® Locking Flat Lever Outside Trim is designed to be used with the 1295 and 2095 Models of Rim Panic Exit Devices. It has a narrow 1-3/4" (45 mm) escutcheon that allows it to be used on narrow stile doors, as well as hollow metal and wood doors. The flat style lever is key-controlled, and requires the use of Cat. No. DRA10 Series Keyed Mortise Cylinder. Hardware available for 4 thicknesses of doors: 1-3/4", 2", 2-1/4", 2-3/8" as well as trimmable tail piece.
CRL Dark Bronze Jackson® Locking Flat Lever Outside Trim with Night Latch Function
9500LVNL02313
