CRL Malibu 316 Brushed Stainless Long-Arm Post Mount Handrail Bracket
CRL Malibu 316 Brushed Stainless Long-Arm Post Mount Handrail Bracket
Regular price
$44.67 CAD
Regular price
Sale price
$44.67 CAD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Item# HR2EPBS
Shipping Weight: 5.12 Ounces
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Shipping Weight: 5.12 Ounces
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Description
Centerline Width Projection
2-15/16 in. (75 mm)
Finish/Color
Brushed Stainless Steel
Material
316 Stainless Steel
Overview
- Available in two sizes: Short Arm and Long Arm
- Fits 1-1/2" to 2" (38 to 50.8 mm) diameter hand rail tubing
- Ready-to-mount to 1-1/4" or 1-1/2" (32 or 38 mm) Schedule 40 vertical posts
- 316 Grade stainless steel — corrosion-resistant architectural hand rail bracket
This CRL Post Mounted Hand Rail Bracket (SKU: HR2EPBS) mounts post-to-rail for 1-1/2" to 2" (38 to 50.8 mm) diameter hand rail tubing and is offered in several architectural finishes. Brackets are individually packed and include attachment screws. Use optional Adapter Plate Cat. No. HBFP1BS for square hand rail applications.
Product Warning:
The CRL HR2EP Hand Rail Bracket mounting stud may be drilled and tapped for M10 x 1.5 or 3/8"-16 thread. Each box is labeled with the correct thread type; please advise customers to review box labels before prepping the post.
Stainless Steel Advisory:
Stainless steel is corrosion-resistant but not completely rust- or stain-proof. CRL recommends periodic maintenance to preserve the factory finish. See the Stainless Steel Disclaimer in Technical References for details.
Shop the HR2EPBS 316 stainless post-mounted hand rail bracket now — contact CRL or add to cart to order.
Specifications
CAD Drawings - pdf
