CRL Matt Gunmetal Fixed Glass Panel Square Clamp - Large Leg
Item# SGC039MGM
Shipping Weight: 11.04 Ounces
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Shipping Weight: 11.04 Ounces
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Case Quantity
50
Finish/Color
Gun Metal
Glazing Thickness
3/8 in. To 1/2 in. (10 mm To 12 mm)
Height
2 in. (51 mm)
Leg Width
2 in. (51 mm)
Length
2
Material
Brass
Mounting Type
Wall Mount
Width
2 in. (51 mm)
- Clamps contribute to an all-glass appearance
- Requires 3/4" (19 mm) hole in glass
- Larger leg covers more wall or tile surface
- Use with monolithic tempered glass
CRL Fixed Panel Square Clamp (large leg) mounts directly to the wall, ceiling or floor to secure vertical fixed glass panels. Clearance between glass and wall is 1/16" (2 mm). Clear silicone provides a clean, water-tight seal. The 90° leg adds strength and the larger leg hides tile for a finished look. Ideal for tempered glass shower panels and frameless glass installations—SKU SGC039MGM.
SPECIFICATIONS:
Materials: Solid Brass
Glass Thickness Range: 3/8" to 1/2" (10 to 12 mm)
Glass Fabrication Required: SGCU1 Requires Notch; SCU4, SGC037, and SGC039 Require 3/4" (19 mm) Holes
Includes: Mounting Screws and Gaskets
