CRL 2-Panel Overhead Single-Track Painted Sliding Door System
CRL 2-Panel Overhead Single-Track Painted Sliding Door System
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Item# 0TS2PT
Shipping Weight: NA
Shipping Limitations: No UPS - Common Carrier Only
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Shipping Weight: NA
Shipping Limitations: No UPS - Common Carrier Only
Request A Quote For A Shipping Rate
Minimum Order Quantity: 1Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Description
Configuration
Single Track 2 Panel Bi-Part
Finish/Color
Powder Coated
Glazing Thickness
3/8 in. (10 mm)
Maximum Panel Width
72 in. (1829 mm)
Series
OT Overhead Track Slider
Overview
- Four-roller units quietly move overhead door rails for smooth sliding operation
- Design provides a flush bottom surface for a clean, low-profile threshold
- Available in multiple configurations and architectural finishes for custom installations
CRL Overhead Track Sliding Door Systems — SKU: 0TS2PT — are offered in four standard configurations. Each sliding panel is suspended from two Cat. No. 0TCA carriage assemblies. Maximum panel weight: 225 lbs. (102 kg). Maximum panel width: 72" (1.83 m). Minimum panel width: 25" (635 mm). These overhead track sliding door systems are ideal for commercial and residential projects requiring a low-profile, durable sliding solution.
NOTE: Available by custom order only. Most orders can be fabricated in five business days at our Los Angeles, California manufacturing facility. Contact CRL Technical Sales Department for additional information.
