CRL SDC® EMLock® Narrow Double Electromagnetic Door Lock
CRL SDC® EMLock® Narrow Double Electromagnetic Door Lock
Regular price
$1,373.26 CAD
Regular price
Sale price
$1,373.26 CAD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Item# SDC352A
Shipping Weight: 22.5 Pounds
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Shipping Weight: 22.5 Pounds
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Description
Brand
SDC EMLock
Certification
ANSI/BHMA Grade 1
Height
2-1/8
Holding Force
1200
Input Voltage
12/24 Volts
Length
25
Type
Double Electromagnetic Lock
Width
1-11/16
Overview
- Narrow-profile electromagnetic lock designed to retrofit discontinued Locknetics® 350/352+ magnetic locks without modifications
- Fully automatic 12/24VDC selectable operation for easy integration
- 1200 lbs. holding force per door leaf — heavy-duty perimeter and interior access control
- Full monitoring standard (door status and lock status)
- ANSI/BHMA Grade 1 compliant for commercial security applications
The CRL SDC352 Narrow Line EMLock® Single Electromagnetic Lock (SKU: SDC352A) is a narrow-profile electromagnetic lock that delivers 1200 pounds of holding force per door leaf. Engineered as a direct retrofit for discontinued Locknetics® 352+ magnetic locks, the SDC352 installs without frame modifications and projects only 2-11/16" (68 mm) into the opening, making it ideal for narrow frames and commercial door retrofit projects. This fail-safe access control magnetic lock meets building security and fire life safety requirements while providing full monitoring for door and lock status.
SPECIFICATIONS:
Current Draw:
12 Volt Current Draw: 1080 mA
24 Volt Current Draw: 600 mA
Dimensions:
L = 25" (635 mm) x H = 2-1/8" (54 mm) x W = 1-11/16" (43 mm)
Weight: 22.5 lbs. (10.2 kg)
Need a narrow-profile, fail-safe electromagnetic lock that retrofits Locknetics® models? Order the SDC352A today or contact CRL for technical support and installation guidance.
