CRL Black 1/8" x 3/4" Single-Sided Self-Adhesive Foam Glazing Tape

• Excellent adhesion to wood, vinyl (rigid PVC), aluminum, and glass
• Superior resistance to weathering, oxidation, and UV exposure
• Meets AAMA 810.1 certification
• Aggressive acrylic adhesive for curved or irregular surfaces
• Service temperature range: −40°F to 180°F (−40°C to 82°C)
• Available colors: Gray and Black

CRL Foam Glazing Tape is a closed-cell polyethylene foam glazing tape designed for exterior and interior glazing applications. The aggressive acrylic adhesive bonds to wood, vinyl, aluminum, and glass and allows positioning on curved or irregular surfaces with light pressure. Use as a primary or secondary seal in windows, doors, demountable partitions, louvers, access panels, and other operable or temporary joints where repositioning before final setting is important.

This self-shimming, patented cellular foam resists water absorption and provides a long-lived seal without shims or spacers. Joints sealed with tape (adhesive on one side) can be opened, closed, and repositioned without the sticky mess of liquid sealants. The non-adhesive face releases cleanly from most surfaces and the tape recovers most of its original thickness after compression.

Key features

• Simplicity: no mixing, no special tools, no clean-up
• Preformed tape for consistent, accurate application—no shim required
• Remains flexible at low temperatures and dimensionally stable at high temperatures
• Non-yellowing, non-staining, water-white adhesive for a clean appearance
• Seals effectively against water, dust, and light
• Available in a variety of sizes

Maintain a minimum of 30% compression for effective moisture sealing (manufacturer notes vary—see product warning). In small lites, compression may be achieved by applying pressure when installing glazing stops; in most lites a compression wedge gasket is recommended. Apply with firm, uniform pressure to a clean, dry surface without stretching. Cut and butt corners rather than overlapping; apply a thin bead of approved sealant at intersections after liner removal. Compatible with other sealing and glazing compounds.

Certifications & environmental
CRL is an ENERGY STAR® partner and our fenestration foam glazing tapes carry the ENERGY STAR® seal for energy-efficient window and door assemblies.

Product warning
CRL Vinyl Foam Glazing Tape must be compressed (manufacturer indicates minimum compression) to maintain an effective seal. Use a compression wedge gasket in most installations for reliable performance.
