CRL Brushed Nickel 180Β° Beveled Glass Clamp for Frameless Shower
CRL Brushed Nickel 180Β° Beveled Glass Clamp for Frameless Shower
Regular price
$46.58 CAD
Regular price
Sale price
$46.58 CAD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Item# BGC180BN
Shipping Weight: 1.22 Pounds
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Shipping Weight: 1.22 Pounds
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Description
Design Style
Beveled
Enclosure Type
Tailor Made Solutions
Finish/Color
Brushed Nickel
Glass To Glass Angle
180
Glazing Thickness
3/8 in. To 1/2 in. (10 mm To 12 mm)
Material
Brass
Mounting Type
Glass To Glass
Overview
- For 3/8" to 1/2" (10 to 12 mm) thick glass
- Secures fixed glass panels in frameless shower enclosures
- Solid brass construction with beveled edge finish
- Creates an 'all-glass' look as an alternative to U-channel
- Glass fabrication required; use monolithic tempered glass
CRL Beveled 180ΒΊ Glass-to-Glass Clamps β SKU: BGC180BN have attractive beveled edges and solid brass construction, engineered to connect two fixed transom or inline glass panels in frameless shower enclosures and custom glass partitions. Ideal for frameless shower clamps, glass-to-glass connectors, transom connectors, showcases, trophy cases, and other architectural all-glass installations. Available in finishes that coordinate with CRL door hinges and clamp lines. Drawings and templates available for installation planning.
SPECIFICATIONS:
Materials: Solid Brass
Glass Thickness Range: 3/8" to 1/2" (10 to 12 mm)
Glass Fabrication Required: BGC180, BGC135, BGC90, and BGC186 require 3/4" (19 mm) holes; BGC188 requires a 3/4" (19 mm) hole in the fixed panel and a notch in the transom
Includes: Gaskets
