CRL Chrome 1/2 in 90° Open Center Clamp Type E - Stair Railing Clamp
CRL Chrome 1/2 in 90° Open Center Clamp Type E - Stair Railing Clamp
Regular price
$31.73 CAD
Regular price
Sale price
$31.73 CAD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Item# RH1112CH
Shipping Weight: 5.92 Ounces
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Shipping Weight: 5.92 Ounces
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Description
Base Type
Flat
Depth
3/4 in. (19 mm)
Finish/Color
Chrome
Glazing Thickness
1/2 in. (13 mm)
Height
1-7/8 in. (48 mm)
Material
Solid Brass
Width
1-7/8 in. (48 mm)
Overview
- Chrome, Brass, and Brushed Nickel finishes
- Custom finishes available on request
- For 1/2" (12 mm) tempered glass
Use the CRL 90 Degree Straight Open Center Clamp 'E' (SKU: RH1112CH) on the top or bottom midpoint of glass in level runs. Reversible open-center design for easy left/right installation. Ideal as a glass railing clamp for 1/2 inch tempered glass in residential and commercial railing, partition, and room divider systems.
Replacement screws: P612**
Our glass and railing clamps are predrilled and ready for fast installation. Two sizes accommodate 3/8" or 1/2" (10 or 12 mm) tempered glass. Three stock finishes plus custom finishes are available. Install in seconds: loosen screw on one end, insert the glass edge, then retighten. Use CRL Tuff-Pak Tape to cushion the glass. For wood mounting use Screw Cat. No. 8X212DW; for metal mounting use Screw Cat. No. FHSTMSS. Drawings and templates for all clamps are available on request.
A: Acute End Clamp for slanted railings
B: Open Center Clamp for slanted railings
C: Obtuse End Clamp for slanted railings
D: Straight End Clamp for level railings
E: Straight Open Center Clamp for level railings
Order SKU RH1112CH or contact CRL Customer Service for custom finishes and technical drawings.
Specifications
Templates
