CRL Smoke Baffle Base Shoe, Satin Brass Clad for 1/2" Glass Door
CRL Smoke Baffle Base Shoe, Satin Brass Clad for 1/2" Glass Door
Regular price
$0.00 CAD
Regular price
Sale price
$0.00 CAD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Item# B5BSBC
Shipping Weight: NA
Shipping Limitations: No UPS - Common Carrier Only
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Shipping Weight: NA
Shipping Limitations: No UPS - Common Carrier Only
Request A Quote For A Shipping Rate
Minimum Order Quantity: 1Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Description
Drilling Center To Center
Specify
Finish/Color
Satin Brass
Glass Included
No
Glazing Thickness
1/2 in. (13 mm)
Height
2-51/64 in. (71 mm)
Length
Specify
Material
Aluminum
Width
1-17/32 in. (39 mm)
Overview
- For fabricating almost invisible 1/2" (12 mm) tempered glass smoke curtains
- Glass mechanically secured with fasteners and nylon grommets (3/4" / 19 mm holes on 12" / 305 mm centers)
- Custom drilling, mitering, and cutting services available
CRL Smoke Baffle Aluminum Base Shoe — SKU: B5BSBC is an extruded aluminum base shoe designed to suspend a near-invisible 1/2" (12 mm) tempered glass smoke curtain from the ceiling. Ideal for sectioning large open-plan offices or retail spaces to meet fire-code requirements, smoke baffles retain smoke within a specified area and can help prevent unnecessary sprinkler activation. The base shoe fastens to the ceiling structure and supports glass panels that hang straight down; glass is secured using screws through nylon grommets. A glass fabrication template is included. Available in multiple architectural cladding finishes for seamless integration with interior designs.
Product Warning:
Products manufactured by C.R. Laurence Co., Inc. (CRL) with an Oil Rubbed Bronze finish are inspected prior to shipping. Within two days of receipt, open the package, remove protective wrap, and inspect the finish. Report any damage or irregularity to CRL immediately; damages reported later may not be honored. Check local building codes for ceiling area square footage and required depth specifications for glass curtains.
Brass Finish Advisory:
Brass finishes are durable but prone to oxidation, which can cause tarnishing regardless of packaging or storage. See the Brass Finish Disclaimer in Technical References for care guidance.
Need help specifying or ordering this aluminum smoke baffle base shoe (SKU B5BSBC)? Contact CRL or request a quote today.
