CRL Jackson® Model 2086 with Impact Kit Concealed Vertical Rod Panic Exit Device Left Hand Reverse Bevel Fits 4/0 x 7/0 Door Satin Aluminum Finish

Item # 3120861L47628

$877.95 CAD

Finish (2)

Overview

SKU3120861L47628
Sold As1 Each
BrandJackson
CertificationANSI/BHMA 156.3, Grade1
Door Height84 in. (2133.6 mm)
Door Thickness1-3/4 in. (44.5 mm)
Door Width48 in. (1219.2 mm)
Finish/ColorAluminum
HandingLeft Hand Reverse Bevel (LHR)
Impact Panic Hurricane ResistantYes
IncludesMounting Hardware
Material - End CapAluminum
Material - HousingAluminum
Material - Latch & StrikeSintered Steel
Material - Mechanical ComponentsStainless and Hardened Plated Steel
Minimum Stile Width1-3/4 in. (44.5 mm)
Model2086
Panic Bar Base Height2-7/8 in. (73 mm)
Panic Bar Projection3 in. (76.2 mm)
Panic Bar Width Net46-1/2 in. (1181.1 mm)
Panic DoggingPush Button
Panic Head Height7-5/16 in. (185.7 mm)
Panic TypeConcealed Vertical Rods Top Bolt
Push Pad Width23-1/2 in. (596.9 mm)
Recommended Door TypeAluminum Narrow, Medium, Wide Stile, Hollow Metal
Series20
Tall Door Extention Rods301347301348
UL ListedYes

Description

  • Includes Impact Kit
  • Remarkably Quiet, Smooth, Reliable Operation
  • Use with Narrow, Medium and Wide Stile Aluminum Doors
  • Durable, ANSI 156.3 Grade 1, Tested to Over 500,000 Cycles
  • Easy Concealed Push-Button Dogging Standard. Cylinder Dogging Available

CRL Jackson® Model 2086 with Impact Kit Concealed Vertical Rod Panic Exit Devices are UL Listed - Certified ANSI 156.3 Grade 1, and manufactured in the Jackson® tradition of high quality and durability. This device with the Impact Kit has been used in a number of OEM Certified Impact systems. Suitable for use with narrow, medium and wide stile aluminum doors, these devices are handed - not reversible, and feature dual point hex bolt latching, concealed easy-to-use push button dogging, "Soft Touch" smooth quiet action push pad, and quick and easy installation. They are available in Dark Bronze and Satin Aluminum anodized finishes. Standard devices come in two lengths for 36" and 48" wide doors, and can be cut down to custom fit an opening (consult CRL Jackson® Technical Sales Department). For doors over 84" order Top Rod Extender: 12" - 301347 or 24" - 301348. Devices may be ordered with optional Cylinder Dogging, which uses a 1-1/8" Mortise Cylinder such as DC7185SCKADU, ordered separately. Keyed entry may be provided by ordering and installing a standard 1" Mortise Cylinder such as DL2170SCKDA with AR MS type cam, along with a Cylinder Mounting Pad such as 30821J628. Keyed access is also available with Jackson® Model 8500LV Outside Lever Trim such as 8500LV02628.


REPLACEMENT PARTS:
  • 301266628
  • 301265628
  • 302462LI>301084628
  • 30763P
  • 301552
  • 30824628
  • 301311PKG
  • 308621J628
  • DL2170SCKDA
  • 302989628
