CRL Polished Brass Half Round Light Duty Frameless Shower Door Hinge
CRL Polished Brass Half Round Light Duty Frameless Shower Door Hinge
Regular price
$104.99 CAD
Regular price
Sale price
$104.99 CAD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Item# EH186
Shipping Weight: 6.8 Ounces
Shipping Limitations: None
Warning: Reproductive Harm
www.p65warnings.ca.gov
Minimum Order Quantity: 1
Unit of Measure: Pack of 1
Shipping Weight: 6.8 Ounces
Shipping Limitations: None
This Product Ships Free!
Compliance and RestrictionsWarning: Reproductive Harm
www.p65warnings.ca.gov
Minimum Order Quantity: 1
Unit of Measure: Pack of 1
Description
| 5 Degree Pre-Set No | No |
| Back | Plate Offset |
| Edge | Profile Square |
| Finish/Color | Polished Brass |
| Glazing Thickness | 1/4 in. To 5/16 in. (6 mm To 8 mm) |
| Height 2-3/16 in. | (56 mm) |
| Material | Brass |
| Maximum Door Weight - 2 Hinges 50 lbs. | (22.7 kg) |
| Maximum Door Weight - 3 Hinges 75 lbs. | (34 kg) |
| Maximum Door Width 24 in. | (610 mm) |
| Mounting | Type Wall Mount |
| Width 1-1/2 in. | (38 mm) |
Overview
CRL Half Round Hinges are ideal for showcase applications, accommodating glass thicknesses from 1/4" to 5/16" (6 to 8 mm).
Installation requires a 1/2" (12 mm) hole, and each package includes two hinges backed by a three-year warranty.
Designed for use with monolithic tempered glass, these hinges support a maximum width of 24" (610 mm) and a weight limit of 50 lbs.
(23 kg).
Ensure to use the included template for precise cut-outs, as dimensions may differ from other brands.
For any purpose beyond residential or hotel shower use, approval from the CRL Shower Door Technical Sales Department is necessary.
Please note, the brass finish may oxidize over time; see the Brass Finish Disclaimer in the Technical References section for more details.
Contact CRL Customer Service for accurate shipping weight and cost details.
Installation requires a 1/2" (12 mm) hole, and each package includes two hinges backed by a three-year warranty.
Designed for use with monolithic tempered glass, these hinges support a maximum width of 24" (610 mm) and a weight limit of 50 lbs.
(23 kg).
Ensure to use the included template for precise cut-outs, as dimensions may differ from other brands.
For any purpose beyond residential or hotel shower use, approval from the CRL Shower Door Technical Sales Department is necessary.
Please note, the brass finish may oxidize over time; see the Brass Finish Disclaimer in the Technical References section for more details.
Contact CRL Customer Service for accurate shipping weight and cost details.
