• CM12X28PS polished stainless steel straight glass-mounted push/pull handle, 1 in diameter, fits 3/8-3/4 in glass
1 1

CRL

CRL Polished Stainless 12x28 Back-to-Back Glass Push-Pull Handle Set

CRL Polished Stainless 12x28 Back-to-Back Glass Push-Pull Handle Set

$186.89 CAD
$186.89 CAD
Sale Sold out
Shipping calculated at checkout.
View More Information Buy More, Save More
Item# CM12X28PS
Shipping Weight: 2.565 Pounds
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
View full details

Product Information

Description

Diameter
1 in. (25 mm)
Finish/Color
Polished Stainless Steel
Glazing Thickness
3/8 in. To 3/4 in. (10 mm To 19 mm)
Mounting Hole Diameter
5/8 in. (16 mm)
Mounting Type
Back-to-Back
Pull Mounting Center To Center
12 in. (305 mm)
Push Mounting Center To Center
28 in. (711 mm)
Style Washer Diameter
1-1/4 in. (32 mm)
Style Washers
Yes

Overview

  • For use with 3/8" to 3/4" (10 to 19 mm) glass
  • 1" (25.4 mm) diameter stainless steel or brass tubing
  • Five architectural finishes for interior and exterior glass doors
  • Designed for monolithic tempered glass doors

CRL Glass-Mounted Straight Push/Pull Handle Combination — SKU: CM12X28PS — heavy-duty glass door pull for commercial and residential tempered glass doors. Available in multiple sizes and attractive architectural finishes to match storefronts, office interiors, and shower enclosures.


SPECIFICATIONS:

For Use With: 3/8" to 3/4" (10 to 19 mm) glass

Construction: 1" (25 mm) diameter stainless steel or brass tubing

Glass Fabrication Required:

  • Three 5/8" (16 mm) diameter holes
  • 10" (254 mm) center-to-center
  • 12" (305 mm) center-to-center
  • 28" (711 mm) center-to-center
  • 33" (838 mm) center-to-center

Offset: 3" (76 mm) center-to-center

Optional: 1-1/4" (32 mm) diameter available on special order


INCLUDES:

  • 2 — through-bolts for glass mounting
  • 4 — 1-1/4" (32 mm) diameter matching finish metal washers and rubber gaskets

Most shipping weights are approximate and have not been verified. If exact weight or shipping costs are required to complete your order, contact CRL Customer Service prior to submitting your order. Product images represent the actual product or a close representation; colors may vary by monitor.

Stainless Steel Advisory:
Stainless steel is corrosion-resistant but not impervious to rust or staining. Periodic maintenance is recommended to preserve the factory finish. See the Stainless Steel Disclaimer in Technical References for maintenance guidance.


Durable, visually clean, and engineered for tempered glass doors — order SKU CM12X28PS or contact us for finish availability and lead times
