CRL 12 in Satin Anodized Aluminum Mounting Bracket

• Available in five finishes and five lengths: 4", 6", 8", 10", and 12" (102, 152, 203, 254, and 305 mm)
• Fits CRL Series 22 and Series 322 aluminum standards only — not compatible with steel standards or other manufacturers' systems
• SKU: 122A12 — CRL aluminum shelf brackets for hidden-slot mounting

CRL Aluminum Brackets slip into the hidden slots of Series 22 and 322 aluminum standards and are secured by tapping down—no back flange required. Designed for adjustable, clean-looking shelving installations where a concealed bracket is desired.

Aluminum Bracket Weight Capacities (based on two standards mounted 16" / 406 mm apart with screws into wall studs):
4" (102 mm) = 75 lbs (34 kg)
6" (152 mm) = 65 lbs (29 kg)
8" (203 mm) = 55 lbs (25 kg)
10" (254 mm) = 45 lbs (20 kg)
12" (305 mm) = 35 lbs (16 kg)

Installation & glass shelf note: Deduct 1/16" from the depth of the glass shelf when using these aluminum brackets.

Product Warning: These aluminum brackets are not interchangeable with steel standards or bracket systems from other manufacturers. Use only with CRL Series 22 or Series 322 aluminum standards.

Order CRL aluminum shelf brackets (SKU 122A12) for a clean, concealed mounting solution—select finish and length to match your Series 22 or 322 aluminum standards.
