CRL 48 in Satin Anodized Sliding Upper & Lower Track w/Nylon Wheels

• Available in Three Convenient Pre-Cut Lengths
• Satin Anodized and Brushed Nickel Finishes

These smooth-operating track assemblies deliver years of reliable service. CRL's Low Profile Track Assembly (SKU: D2203A48) is sold in three popular pre-cut lengths for minimal material waste — an efficient choice for glass pass-thru and bypassing door installations.

All required track assembly components are packed in a convenient shipping tube and are easy-to-install. The two-piece "H" bar for bypassing doors provides a 1-1/2" (38 mm) overlap. CRL Cat. No. D332 End Caps for the "H" Bar and GC728C vinyl for dry glazing with 1/4" (6 mm) glass are available separately. For secure installations, CRL offers a large selection of ratchet and plunger-type locks.

NOTE: Maximum suggested panel size is 36" W x 48" H (914 mm x 1.22 m).

General Glass Cutting: Glass Height = Opening Height minus 1-1/8" (28.6 mm).

Components for D2203A

D602 (x1)
D603 (x1)
D650 (x12)
D610 (x1)
D652 (x12)
D9650 (x1)


Product Warning:

If a very tight fit is required, confirm your own final dimensions. The dimensions shown are guideline dimensions satisfactory to most installers.

D2203 Series = Rolling Track Assembly : Glass Height = Opening Minus 1-1/8"
D2204 Series = Rolling Track Assembly : Glass Height = Opening Minus 1-1/8"
D2300 Series = Rolling Track Assembly : Glass Height = Opening Minus 1-3/8"
D2301 Series = Rolling Track Assembly : Glass Height = Opening Minus 1-3/8"
D2303 Series = Rolling Track Assembly : Glass Height = Opening Minus 1-3/8"
D2305 Series = Rolling Track Assembly : Glass Height = Opening Minus 1-3/8"
D2306 Series = Rolling Track Assembly : Glass Height = Opening Minus 1-5/8"
D2307 Series = Rolling Track Assembly : Glass Height = Opening Minus 1-5/8"
