- Available in Three Convenient Pre-Cut Lengths (36", 48", 72")
- Includes Combination Bottom Track for Matched Upper/Lower Design
- Finishes: Satin Anodized and Brushed Nickel
The
CRL Deluxe Track Assembly (SKU D2301A72) is a smooth-working, reliable sliding glass door track assembly designed for easy installation and long-term performance. Offered in three pre-cut lengths—36", 48", and 72" (914 mm, 1.22 m, and 1.83 m)—this pre-cut sliding door track reduces installation time and material waste. The 'H' Bar is factory-cut to allow a 1-1/2" (38 mm) overlap, and the combination lower channel matches the upper channel for a consistent, finished look.
CRL Cat. No. D332 end caps for the 'H' bar extrusion are sold separately. For dry glazing with 1/4" (6 mm) glass use Cat. No. GC728C vinyl (sold separately). CRL offers a selection of ratchet and plunger type locks to secure sliding glass doors.
NOTE: Maximum suggested panel size is 36" W x 48" H (914 mm x 1.22 m).
General Glass Cutting Guidelines: Glass Height = Opening Height Minus 1-3/8" (35 mm).
Components for
D2301A
D601 (x2)
D603 (x2)
D610 (x1)
D650 (x12)
D652 (x12)
D9650 (x1)
Product Warning:
If you need a very tight fit, calculate your own final dimensions. The dimensions shown are guideline dimensions suitable for most installers.
Series glass height guidance (sliding glass door/rolling track assemblies):
D2203 Series = Glass Height = Opening Minus 1-1/8"
D2204 Series = Glass Height = Opening Minus 1-1/8"
D2300 Series = Glass Height = Opening Minus 1-3/8"
D2301 Series = Glass Height = Opening Minus 1-3/8"
D2303 Series = Glass Height = Opening Minus 1-3/8"
D2305 Series = Glass Height = Opening Minus 1-3/8"
D2306 Series = Glass Height = Opening Minus 1-5/8"
D2307 Series = Glass Height = Opening Minus 1
