CRL 72 in Satin Anodized Sliding Door Track D603/D602 w/ Nylon Wheels

• Available in three convenient pre-cut lengths
• Satin anodized and brushed nickel finishes

These track assemblies deliver smooth operation and years of reliable service. CRL's Low Profile Track Assembly (SKU: D2203A72) is a space-saving, low profile sliding glass door track assembly available in three popular pre-cut lengths—an efficient choice for pass-thru openings that minimizes material waste.

All required track assembly components are packed in a convenient shipping tube and are easy to install. The two-piece 'H' bar for bypassing doors provides a 1-1/2" (38 mm) overlap. CRL Cat. No. D332 end caps for the 'H' bar are available separately. For dry glazing with 1/4" (6 mm) glass use Cat. No. GC728C vinyl (sold separately). For security options, see CRL ratchet and plunger type locks.

NOTE: Maximum suggested panel size: 36" W x 48" H (914 mm x 1.22 m).

General glass cutting guideline: Glass Height = Opening Height minus 1-1/8" (28.6 mm).

Components for D2203A:

D602 (x1)
D603 (x1)
D650 (x12)
D610 (x1)
D652 (x12)
D9650 (x1)

Product warning:
If you need a very tight fit, calculate your own dimensions. The dimensions shown are guideline dimensions satisfactory to most installers.

Series glass height guidelines:
D2203 Series = Opening Minus 1-1/8"
D2204 Series = Opening Minus 1-1/8"
D2300 Series = Opening Minus 1-3/8"
D2301 Series = Opening Minus 1-3/8"
D2303 Series = Opening Minus 1-3/8"
D2305 Series = Opening Minus 1-3/8"
D2306 Series = Opening Minus 1-5/8"
D2307 Series = Opening Minus 1-5/8"

Order the low profile sliding glass door track assembly (SKU: D2203A72) today to streamline your pass-thru installation.
