CRL-U.S. Aluminum 550 KYNAR® Wide-Stile Geared Hinge Entrance Doors

• Includes active and inactive leaf with all standard hardware (handles and pivots boxed separately to prevent transit damage)
• Accommodates 1/4" (6 mm) tempered glass; optional 1" (25 mm) tempered insulating unit compatible (glass not included)
• 7-1/2" (191 mm) bottom rail
• Custom fabricated to accept a wide range of optional hardware applications, including offset pivot hardware

This Custom Wide Stile Entrance Door (SKU HE52971) features 5" (127 mm) stiles, a 5-1/2" (140 mm) top rail, and a 7-1/2" (191 mm) bottom rail. Designed for commercial and residential entry projects that require a strong, customizable wide-stile solution, it is prepared for offset pivot hardware and includes glass stops sized for 1/4" (6 mm) tempered glass supplied by others. Ready for custom fabrication to support additional optional hardware applications.

Customer must install included protruding hardware (handles, pivots, etc.) that is boxed separately to prevent damage in transit.

Order or request a quote for SKU HE52971 to specify glass and optional hardware—contact CRL Customer Service to get started.
