CRL-U.S. Aluminum Series 550 Clear Anodized Wide-Stile Hinge Pair
CRL-U.S. Aluminum Series 550 Clear Anodized Wide-Stile Hinge Pair
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Item# DE52911
Shipping Weight: NA
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: Pair
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Shipping Weight: NA
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: Pair
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Description
Finish/Color
Clear Anodized Class 1
Overview
- Includes active and inactive leaf with all standard hardware
- 9-1/2" (241 mm) bottom rail installed to comply with A.D.A.
- Custom fabricated to accept optional hardware applications
- Accommodates 1/4" (6 mm) tempered glass or optional 1" (25 mm) tempered insulating unit (glass not included)
This Custom Wide Stile Entrance Door (SKU: DE52911) is designed for commercial storefronts and high-traffic openings. It features 5" (127 mm) stiles, a 5-1/2" (140 mm) top rail, and an ADA-compliant 9-1/2" (241 mm) bottom rail. Standard preparation includes stiles for Gear Hinge hardware and glass stops for 1/4" (6 mm) tempered glass. The door is custom fabricated to accept a wide range of optional hardware applications, making it ideal for tailored commercial entrance solutions.
Protruding hardware (handles, pivots, etc.) is boxed separately to prevent transit damage and must be installed by the customer upon receipt.
Specifications
BIM Objects - rvt
