CRL 316 Brushed Stainless L10 Series U-Channel 135 Degree Horizontal Corner for 21.52 mm Laminated Glass Cap Railing

Buy More, Save More!

Product quantity Discount
Buy 3 2% off
Buy 5 4% off
Buy 10 6% off
Buy 15 8% off
Buy 20 10% off

Overview

SKUL10H3BS
Pack Size1
Angle135
Centerline5-1/4 in. (133 mm)
Finish/Color:Brushed Stainless Steel
Glazing Thickness1/2 in. (13 mm)
Length6 in. (152 mm)
Material316 Stainless Steel

Description

Product Details

  • Welded and Finished
  • Ready-to-Install
  • 316 Stainless Alloy
  • Use Laminated Tempered Glass

This CRL 135 Degree Horizontal Corner for 27/32" (21.52 mm) thick laminated glass allows for hairline joint assemblies with straight lengths of CRL Cap Rail. Use of our LR21PV Cap Railing Rubber Insert and 95CBL Silicone is required to achieve a secure and permanent bond.

NOTE: When used with 27/32" (21.52 mm) glass, our LR21PV Cap Railing Rubber Insert and 95CBL Silicone should be used to secure the glass.

For more information contact CRL Railing Products Technical Sales Department.

Stainless Steel Advisory:

Although Stainless Steel is resistant to corrosion, it is not rust or stain proof. CRL recommends periodic maintenance to help maintain its factory finish. For more information, view the Stainless Steel Disclaimer found in the Technical References section below.

Specifications
