CRL 316 Brushed Stainless Surface-Mount Square Glass Clamp 3/4in
CRL 316 Brushed Stainless Surface-Mount Square Glass Clamp 3/4in
Regular price
$65.84 CAD
Regular price
Sale price
$65.84 CAD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Item# Z734BS
Shipping Weight: 1.19 Pounds
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Shipping Weight: 1.19 Pounds
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Description
Base Type
Radius
Depth
3/4 in. (19 mm)
Finish/Color
Brushed Stainless Steel
Glazing Thickness
3/4 in. (19 mm)
Height
2-5/16 in. (59 mm)
Material
316 Stainless Steel
Profile
Square
Width
2-1/8 in. (54 mm)
Overview
- For 3/4" (19 mm) tempered glass — radius surface mounting
- Designed for 2" (51 mm) diameter round tubing
- 316 alloy stainless steel construction — corrosion-resistant railing clamp for interior and exterior use
- Use with monolithic tempered glass (requires 7/8" / 22 mm finger notch and included steel pin for 3/4" glass)
CRL Replacement Gaskets are available for both square and round Z-Clamps and for 1/4", 1/2", 3/8", and 5/8" (6, 12, 10, and 16 mm) thick glass. Two gaskets per pack.
SPECIFICATIONS:
SKU: Z734BS
Glass Thickness: 3/4" (19 mm)
Base Design: Radius surface mount
For Use With: 2" (51 mm) diameter round tubing
Material: 316 alloy stainless steel
Glass Fabrication: One 7/8" (22 mm) diameter finger notch required. Included steel pin must be used for 3/4" (19 mm) glass applications.
Includes: Rubber gaskets and steel pin
Product Warning:
For interior and exterior applications CRL recommends pinning each glass panel as required when the glass is not supported from the bottom edge to prevent panel slippage. Rubber gaskets and steel pins are provided with each clamp.
Stainless Steel Advisory:
Stainless steel is corrosion-resistant but not completely rust- or stain-proof. CRL recommends periodic maintenance to preserve the factory finish. See the Stainless Steel Disclaimer in Technical References for more information.
Durable 316 stainless glass clamp for 3/4" tempered glass and 2" round railing systems — order SKU Z734BS today for reliable, code-friendly glass railing installations.
